Vortex Radian™ Leveling Head - Precision Leveling Head ±15°, ARCA-SWISS

Overview

The Vortex Optics Radian™ Leveling Head is a rugged leveling head designed for demanding sport shooters, hunters, and observers. Compatible with Vortex spotting scopes and binoculars, it delivers quick and precise leveling thanks to its rubberized twist-lock grip. It can also replace the ball head of the Radian tripod, for a lighter setup without compromising performance.

Technical Specifications

• Leveling range: ±15° in all directions, for precise positioning even on sloped terrain
• Mount: ARCA-SWISS compatible, supplied with a quick-connect plate (1/4-20 thread)
• Load capacity: up to 20 kg (44 lbs), sufficient for even the heaviest spotting scopes
• Height: 20.3 cm (8.0 inches)
• Weight: 476 g (16.8 oz), for a lightweight optics setup in the field
• Material: aluminum, combining lightness and strength
• Center column: short, with integrated counterweight hook to stabilize the setup in strong wind

Advantages

• Simple twist-lock grip for intuitive tension control, no tools required
• Universal ARCA-SWISS compatibility with numerous existing spotting optics and mounts
• Interchangeable with the Radian tripod's ball head to adapt the configuration according to use (observation or precision shooting)
• Lightweight aluminum construction, ideal for long outings in the mountains or on stakeout
• Counterweight hook to enhance stability in challenging conditions

Use and Maintenance

The head attaches directly to a compatible tripod and is used with the supplied ARCA-SWISS plate, for quick mounting and removal of the optic. Tension adjustment is done via the rubberized grip at the base: simply turn it to lock or release the leveling movement. For added stability in strong wind, a weight can be hung from the hook located under the center column. This product is covered by Vortex's lifetime VIP™ warranty.
